XZAC4219-05 Service Manual
1-1
Chapter 1 - OVERVIEW
INTRODUCTION
The PR2 plus is a mid-range specialized printer for the banking environment able to handle documents (both multi-
copy and not) and passbooks for deposit/withdrawal transactions.
This highly versatile printer can also be used for Public Administration front-office transactions or in Post Offices.
The PR2 plus SC model of the printer integrates a colour scanner with a front/back 600 dpi resolution The printer
can be configured with the following optional components:
• "Horizontal Magnetic" unit for reading/writing horizontal magnetic stripes
• MICR
(Magnetic Ink Character Reader) unit for reading CMC7 / E13B characters printed on cheques.
• Con
sole with optional LCD display (shown in the following figure).
The PR2 Plus printer is available with or without an LCD display.
The table below indicates the different configurations in which the PR2 Plus printer is available:
Figure 1 - 1 PR2 Plus Printer
VERSION CONFIGURATION
PR2 plus 10
Basic model with RS232, Parallel and USB ports
Basic Model - Passport version
PR2 plus SC Model PR2 plus 10 with scanner
PR2 plus 12 PR2 plus 10 with horizontal magnetic unit
PR2 plus 12 M PR2 plus 12 with horizontal magnetic unit and MICR reader
