XZAC4219-05 Service Manual
5-9
ERROR
Magnetic Reset
No timeout
Horizontal magnetic or MICR module error on reset sequence
Replace the horizontal magnetic or MICR interface card. See the
section “Horizontal magnetic/MICR disassembly/reassembly” on
page 7 - 28.
ERROR
Motor Carriage
No timeout
Motor carriage reset error
See the section “Faults with document handling” on page 5 - 19.
Scanner error
FPGA LOAD
No timeout
Error on programming FPGA scanner.
• Perform calibration of the scanner. See the section
“Calibrating the scanner” on page 4 - 28
• Replace the motherboard. See the section “Disassembling/
reassembling the motherboard (printers with scanner)” on
page 7 - 21.
Scanner error
AFE TALK
No timeout
Analog Front End seria comunication error
• Perform calibration of the scanner. See the section
“Calibrating the scanner” on page 4 - 28
• Replace the CIS. See the sections: “CIS assy (upper scanner)
disassembly/reassembly” on page 7 - 33 and “CIS assy (lower
scanner) disassembly/reassembly” on page 7 - 34.
Scanner error
STATIC RAM
No timeout
Static RAM error scanner.
Replace the motherboard. See the section “Disassembling/
reassembling the motherboard (printers with scanner)” on page 7 -
21.
Scanner error
DYNAMIC RAM
No timeout
Dynamic RAM error scanner.
Replace the motherboard. See the section “Disassembling/
reassembling the motherboard (printers with scanner)” on page 7 -
21.
Make SCANNER
Calibration
No timeout
Adjustment scanner area corrupted or not valid.
Perform the scanner calibration.
• Press any key on the console to display the next anomaly,
when necessary.
• Perform calibration of the scanner. See the section
“Calibrating the scanner” on page 4 - 28.
MESSAGE TIME OUT DESCRIPTION
