4 Setting the Controller
4 - 14
Vision System FH/FHV/FZ5 Series User’s Manual (Z365)
A guide to using the most suitable operation mode for your purpose.
Selection Guide for Operation mode
Multi-line Random-trig-
ger mode
Non-stop Adjustment
mode
Double Speed Multi-
input mode
*1
*1. This mode name is changed from Ver. 5.50. This function name is Single-line High speed mode in old model.
Standard mode
*2
*2. This mode name is changed from Ver. 5.50. This function name is High-speed Logging mode in old model.
Refer to Multi-input Function
on page 4-16.
Refer to 1-1-2 Functional Comparison between the FH-series, FHV-series and FZ5-series Controllers
on page 1-3.
• This mode can input the
trigger to each lines.
• Input or Output of com-
munication can be lim-
ited depending on used
the number of lines.
• Processing time may be
longer than Standard
mode if you increase
the number of lines.
• This mode allows
changes to be made to
settings while running
measurement process-
ing.
• Some processing items
may not be applied to
use or may be
restricted.
• Using commands from
the external device are
restricted.
• Unintended operation
may be occurred if you
change the Scene while
this function is running.
• For this Operation
mode, need to use the
Multi-input function.
• This mode allows the
highest number of mea-
surements within a sin-
gle unit of measurement
time.
• In this function, some
processing unit items
are not applied or lim-
ited.
• Using the command
from external device is
limited.
• This mode allows for the
fastest measurement
time for a single mea-
surement.
• All functions can be
used without restriction.
Select Operation mode
You want to measure
on multiple lines.
Measures on multiple lines
: Trigger input for each line.
: Trigger input for each line.
You want to make
adjustments without
stopping
measurement.
Adjust without stopping
machines
: Can change the settings with
measuring.
: A part of the processing
items can be limited.
Executes the measurement as
many as possible by unit time.
:
E
xecutes the measurement alternately
using 2 cores. 2 core for fastest
measurement speed.
: For this measurement, need to use the
Multi-input function.
: A part of the processing items can be
limited.
You want to shorten the
single measurement time.
For fastest
measurement
processing time.
: No limit all f
unctions.
To Next Page
