4 Setting the Controller
4 - 44
Vision System FH/FHV/FZ5 Series User’s Manual (Z365)
• If you are using the Through Image Mode in the Main Window, the SHTOUT signal is output
for every through image that is taken.
2 Select the output signal in the [Common setting].
3 Select the output method of STGOUT signal in the [STGOUT setting].
Please uncheck if you select [SHTOUT] in the [Output signal].
Important
• The setting of [Output even if camera is not connected] can be used only with FH series. This
can not be used with FZ5 series.
• The STGOUT signals that are applicable with the setting [Output even if camera is not con-
nected] are as follows.
• FH-1000/3000/5000 series: STGOUT 0 to 7
• FH-L series: STGOUT 0 to 3
• The setting for Multi-line Random-trigger Mode is as follows.
[Output signal setting]
• Configurable only in Output signal setting of Line 0. For other lines settings for Line 0 are
commonly applied.
[Output even if camera is not connected]
• Selectable for each line.
• If a check is placed for [Output without a Camera connection] , set the pulse width for the
[Camera Image Input FH] processing item of corresponding STGOUT signal (STGOUT0 to
STGOUT7)
Refer to Electronic Flash Setting in the Camera Image Input FH in the Vision System FH/
FHV/FZ5 Series Processing Item Function Reference Manual (Cat. No. Z341).
• STGOUT0 to STGOUT7 is tied to the camera connector number of the sensor controller, not
the camera number. When you use CameraLink Medium Configuration or the Multi-line ran-
dom-trigger mode, confirm the camera connector number that corresponds to the camera
number of Sensor Controller.
Parameter
Set value
[Factory default]
Description
Output signal [STGOUT] The STGOUT signal line is used for the STGOUT signal. If you
selected STGOUT, you cannot use the SHTOUT output signal.
SHTOUT The STGOUT signal line is used for the SHTOUT signal. If you
selected SHTOUT, you cannot use the STGOUT output signal.
Parameter
Set value
[Factory default]
Description
Output without a
Camera connection
• [Unchecked]
• Checked
• Unchecked
Only STGOUT signal with which a Camera is connected is out-
put.
• Checked
STGOUT signals that are not connected with cameras will out-
put, too. This setting can be used to change the brightness of
the light quickly. Use the [Electronic flash setting] in [Camera
image input FH] to configure the STGOUT signal.
