4 - 45
4 Setting the Controller
Vision System FH/FHV/FZ5 Series User’s Manual (Z365)
4-7 Setting the SHTOUT Signal [Output Signal Settings]
4
4 Set SHTOUT for each line in the [Line setting] area.
Important
Do not perform next camera image input processing before SHTOUT signal output is com-
pleted. SHTOUT signal may not be output.
Perform camera image input processing after confirming SHTOUT signal output completion, or
set the SHTOUT signal delay and SHTOUT signal pulse width so that the SHTOUT signal out-
put is completed before camera image input processing.
5 Click the [Close] Button.
Parameter Set value [Factory default] Description
SHTOUT signal delay [μs] [0] to 1,000 Sets the delay time from when exposure is
completed to when the SHTOUT signal turns
ON in increments of 10 μs.
SHTOUT signal pulse width [μs] 40 to 10,000 [5,000] Sets the time to output the SHTOUT signal in
increments of 10 μs.
SHTOUT signal pulse polarity • [Positive]
• Negative
Set the polarity of the SHTOUT signal.
Positive: The SHTOUT signal changes from
OFF to ON when the exposure ends.
Negative: The SHTOUT signal changes from
ON to OFF when the exposure ends.
