5 Creating Measurement Scenes
5 - 42
Vision System FH/FHV/FZ5 Series User’s Manual (Z365)
1 Select the Scene tab on the Edit flow screen.
A list of scenes is displayed. The current scene has a check mark.
2 Select a scene on the scene list to delete and click [Delete].
A “Confirm clear” dialog is displayed.
3 Click [OK].
The selected scene is deleted.
1 Select the Scene tab on the Edit flow screen.
A list of scenes is displayed. The current scene has a check mark.
2 Select a scene on the scene list to edit and click [Editing].
The “Scene maintenance” dialog is displayed.
3 Edit the “Name”, “Author”, and “Description”.
Name: Max. 15 characters (No accented or special characters)
Author: Max. 15 characters
Description: Up to 255 characters
Deleting a Scene
Editing Name or Description of a Scene
