8 Setting Windows
Vision System FH/FHV/FZ5 Series User’s Manual (Z365)
8-3 Arranging Windows [Layout Functions]
8
8-3-1 Arranging Window Elements (Layout Modification)
The following windows can be placed in any place on a single layout. But more than one window with
the same name cannot be placed on a single layout.
Type of Window Parts to be Arrangeable and Changeable
Window type Name displayed at adding to a layout by changing layout
Error window FZ_PanDA.ErrorWindow
Flow display window FZ_PanDA.FlowWindow
Image container window FZ_PanDA.ImageContainerWindow
Judgement display window FZ_PanDA.JudgeWindow
Information display window FZ_PanDA.InformationWindow
Label window FZ_PanDA.LabelWindow
Measurement window FZ_PanDA.MeasureWindow
Image file display window FZ_PanDA.PicutureWindow
Detailed result display window FZ_PanDA.TextWindow
Tool window FZ_PanDA.ToolWindow
Extended window part For details, refer to 8-3-14 Extended Window Parts on page 8-40.
