8 Setting Windows
8 - 42
Vision System FH/FHV/FZ5 Series User’s Manual (Z365)
Setting item
Setting value
[Factory default]
Description
Macro specification Sets macro containing variables to display.
Macro Type
• Macro Unit
• [Scene Macro]
• I/O Macro
Sets which macro variables to display.
Unit Name
0 to 32 characters
[0]
Sets this when [Macro Unit] is selected in [Macro Type]. Spec-
ify the macro unit with a unit number or a unit label character
string.
Only single-byte alphanumeric characters as well as “_&#$@”
can be input.
Format Setting Sets table display related issues.
Row Count
[Blank]
1 to 128
Specifies the variable name for the macro storing the table row
count using up to 32 characters.
However, only those integer type variables within the macro
selected in [Macro Type] can be selected.
If any of the following conditions are met, then regardless of the
settings, the row count will be 1.
• Variable is not specified.
• Specified variable does not exist.
• Value stored in the variable is other than numerical value.
If any of the following conditions are met, then regardless of the
settings, the row count will be 128.
• Value stored in the variable is 129 or higher.
Col. Count [Blank]
Specifies the variable name for the macro storing the table col-
umn count using up to 32 characters.
However, only those integer type variables within the macro
selected in [Macro Type] can be selected.
The range of the column count for the table is from 1 to 32 col-
umns.
If any of the following conditions are met, then regardless of the
settings, the column count will be 1.
• Variable is not specified.
• Specified variable does not exist.
• Value stored in the variable is other than numerical value.
If any of the following conditions are met, then regardless of the
settings, the column count will be 32.
• Value stored in the variable is 33 or higher.
