8-3 Arranging Windows [Layout Functions]
8
8-3-15 Data Grid Window (MDI_DataGrid.dll)
Cell Align [Blank]
Specifies the variable name for character string array that store
the character position per cell using up to 32 characters.
However, only variables in single dimensional array of charac-
ter string types that exist in the macro selected in [Macro Type]
can be specified. The number of array elements must be the
[Row Count] or higher. A separator character “;” needs to be
added between cell data in the same row.
A value stored in variables is below
• 0: Left-aligned
• 1: Center
• 2: Right-aligned
If any of the following conditions are met, regardless of the set-
tings, all cells will be left-aligned.
• Value is not specified.
• Value does not exist.
Cells that meet any of the following conditions, regardless of
the settings, will be left-aligned.
• Value is not specified.
• Value is out of range.
• Specified value is other than a numerical value.
Cell Edit Enable [Blank]
Specifies the variable name for the character string array that
stores editing enabled or disabled per cell using up to 32 char-
acters.
However, only variables in single dimensional array of charac-
ter string types that exist in the macro selected in [Macro Type]
can be specified. The number of array elements must be the
[Row Count] or higher. A separator character “;” needs to be
added between cell data in the same row.
A value stored in variables is below.
• 0: Editing enabled
• Other than 0: Editing disabled
If any of the following conditions are met, regardless of the set-
tings, all cells will be editing disabled.
• Variable is not specified.
• Specified variable does not exist.
Cells that meet any of the following conditions, regardless of
the settings, will be editing disabled.
• Value is not specified.
• Value is out of range.
• Specified value is other than a numerical value.
Setting item
Setting value
[Factory default]
Description
