Cell Data [Blank]
Specifies the variable name for the character string array that
stores the cell data using up to 32 characters.
However, only variables in single dimensional array of charac-
ter string types that exist in the macro selected in [Macro Type]
can be specified. The number of array elements must be the
[Row Count] or higher.
A separator character “;” needs to be added between cell data
in the same row.
Up to 31 characters can be displayed in a single cell.
If any of the following conditions are met, regardless of the set-
tings, all cells will be blank.
• Variable is not specified.
• Specified variable does not exist.
Cells that meet any of the following conditions, regardless of
the settings, will be blank.
• Data is not specified.
Cell Color [Blank]
Specifies the variable name for the character string array that
stores the background color per cell using up to 32 characters.
However, only variables in single dimensional array of charac-
ter string types that exist in the macro selected in [Macro Type]
can be specified. The number of array elements must be the
[Row Count] or higher.
A separator character “;” needs to be added between cell data
in the same row.
The background color is specified by using RGB brightness
and a numerical value calculated with R×65536 + G×256+B.
If any of the following conditions are met, regardless of the set-
tings, color for all cells will be white.
• Variable is not specified.
• Specified variable does not exist.
If any of the following conditions are met, regardless of the set-
tings, color for all cells will be white.
• Value is not specified.
• Specified value is other than a numerical value.
Setting item
Setting value
[Factory default]
Description
