Omron fh-1 series User Manual

8 - 49
8 Setting Windows
Vision System FH/FHV/FZ5 Series User’s Manual (Z365)
8-3 Arranging Windows [Layout Functions]
8
8-3-17 Setting Dialog Box Display Button Window (MDI_DispSet- upBtn.dll)
Setting item
Setting value
[Factory default]
Description
Setup Setting Sets the Setup window.
Unit Label Name [Blank] Specifies the processing unit to start the Setup window using
either a unit number or unit label character string using up to 32
characters.
Only single-byte alphanumeric characters and “_&#$@” can be
input.
External tool [Blank]
Specifies an external tool to start using a character string.
*1
*1. Character strings for external tool startup setting
Macro Func. Sets this before and after starting the Setup window when call-
ing a macro subroutine.
Pre-Process [Blank] Specifies the subroutine name (including *) to execute before
displaying the Setup window using up to 32 characters.
Post-Process [Blank] Specifies the subroutine name (including *) to execute after
closing the Setup window using up to 32 characters.
Control Set this when changing the status of the processing item set-
ting display button window by using a macro.
Control ID 0 to 999 [0] Identifies the operation objects when operating by using a
macro of RaiseOptionEvent function.
Initial Setting Set the startup default conditions.
Initial Status • [Active]
• Inactive
Sets the button operation enabled or disabled when starting up
the sensor controller.
Text & Font Setting Display the setting contents for [Text Setting], [Font Setting],
and [Color Setting].
Text Setting Sets character data to display.
Data Type • [Direct]
•Variable
Sets text data to display on the button.
Direct: Directly input to the [Text Data].
Variable: Specify a system variable or a scene variable of
character string type that defines a character string
to display.
Text Data 0 to 128
Characters [Blank]
Specifies text data to display on the button.
Data Type
(Selected)
• [Direct]
•Variable
Sets text data to display at the button selection.
Direct: Directly input to the [Text Data].
Variable: Specify a system variable or a scene variable of
character string type that defines a character string
to display.
Tex t D ata
(Selected)
0 to 128
Characters [Blank]
Specifies text data to display at the button selection.
Font Setting Set the font setting to display.
Size 1 to 100 [10] Sets the font size.
Style • Bold
•Italic
• Underline
• Strikeout
Sets the font style.
Check the box to set the desired style.
Color Setting • [Fore Color]
• Back Color
• Select Color
Sets the font color, background color, and the background color
at selection.
Fore Color: Set the character color.
Back Color: Set the button color in normal state.
Select Color: Set the button color in selection state.
R: 0 to 255 [16]
G: 0 to 255[16]
B: 0 to 255[16]
