8 Setting Windows

8 - 50

Vision System FH/FHV/FZ5 Series User’s Manual (Z365)

Important

• Set a subroutine name to specify in [Macro Func.] in accordance with the following rules.

*?[Single-byte alphabetical character]?[Single-byte alphanumeric character and _ (under-

score)]

Example: *MEASUREDISP

• In [Control], if using a macro RaiseOptionEvent to operate, then specify the control command

in the event number, and the control parameters in the parameter.
