8 - 55
8 Setting Windows
Vision System FH/FHV/FZ5 Series User’s Manual (Z365)
8-3 Arranging Windows [Layout Functions]
8
8-3-19 Custom Dialog Display Button Window (MDI_ExecuteBtn.dll)
Important
• In [Display mode], there are the following restrictions when [Modeless] is selected.
In dialog scene settings, you can not switch between scenes.
If a custom dialog is started up while displaying another dialog, performing measurement , or
performing communication commands, an error dialog will be displayed and cancel the cur-
rent processing.
• Set subroutine name to specify in [Macro processing (scene macro)] in accordance with the
following rules.
*+[Single-byte alphabetical character]+[Single-byte alphanumeric character and _ (under-
score)]
Example: *MEASUREDISP
• In [Control], if using a macro RaiseOptionEvent to operate, then specify the control command
in the event number, and the control parameters in the parameter.
Text & Font Setting Displays the setting contents for [Text Setting], [Font Setting],
and [Color Setting].
Text Setting Sets character data to display.
Data Type • [Direct input]
•Variable
Sets text data to display on the button.
Direct input: Directly input to the [Text Data].
Variable: Specify a system variable or a scene variable of
character string type that defines a character
string to display.
Text Data Ident [Blank] Specifies text data to display on the button using up to 128
characters.
Data Type
(Selected)
• [Direct input]
•Variable
Sets text data to display at the button selection.
Direct input: Directly input to the [Text Data].
Variable: Specify a system variable or a scene variable of
character string type that defines a character
string to display.
Text Data
(Selected)
0 to 128 characters Specifies text data to display at the button selection using up to
128 characters.
Font Setting Sets the display font.
Size [Blank] Sets the font size.
Style • Bold
•Italic
• Underline
• Strikeout
Sets the font style.
Check the box to set desired style.
Color Setting • [Fore Color]
• Back Color
• Select Color
Sets the font color, background color, and the background color
at selection.
Fore Color: Set the character color.
Back Color: Set the button color in normal state.
Select Color:Set the button color in selection state.
R: 0 to 255 [16]
G: 0 to 255 [16]
B: 0 to 255 [16]
Initial Setting Sets the startup default conditions for the custom dialog display
buttons.
Initial Status [Active]
Inactive
Sets the button operation enabled or disabled when starting up
the sensor controller.
Setting item
Setting value
[Factory default]
Description
