• Set subroutine name to specify in [Set operation] in accordance with the following rules.
*+[Single-byte alphabetical character]+[Single-byte alphanumeric character and _ (under-
score)]
Example: *MEASUREDISP
• In [Control setting], if using a macro RaiseOptionEvent to operate, then specify the control
command in the event number, and the control parameters in the parameter.
Data Type • [Direct Input]
• Variable
Sets text data to display on the button.
Direct input: Directly input to the [Text Data].
Variable: Specify a system variable or a scene variable of
character string type that defines a character
string to display.
Text Data [Blank] Specifies text data to display on the button using up to 128
characters.
Data Type
(Selected)
• [Direct Input]
• Variable
Sets text data to display at the button selection.
Direct input: Directly input to the [Text Data].
Variable: Specify a system variable or a scene variable of
character string type that defines a character
string to display.
Tex t Da ta
(Selected)
[Blank] Specifies text data to display at the button selection using up to
128 characters.
Font Setting Sets the display font.
Size 1 to 100 [10] Sets the font size.
Style • Bold
• Italic
• Underline
• Strikeout
Sets the font style.
Check the box to set desired style.
Color Setting • [Fore Color]
• Back Color
• Select Color
Sets the font color, background color, and the background color
at selection.
Fore Color: Set the character color.
Back Color: Set the button color in normal state.
Select Color: Set the button color in selection state.
R: 0 to 255 [16]
G: 0 to 255 [16]
B: 0 to 255 [16]
Initial Setting Sets the startup default conditions for the custom dialog display
buttons.
Initial Status • [Active]
• Inactive
Sets the button operation enabled or disabled when starting up
the sensor controller.
