8 Setting Windows
8 - 84
Vision System FH/FHV/FZ5 Series User’s Manual (Z365)
Image Button Setting Region
Parameter
Set value
[Factory default]
Description
Event • [Apply and close]
• Close
• Other dialog
• Apply and change dialog
• Change dialog
• Apply
• Get current value
•Set Value
Apply and close: Apply the settings and close the
dialog.
Close: Close the dialog.
Other dialog: Open a child window for the new
dialog.
Apply and change dialog: Apply the settings and open the
specified dialog.
Change dialog: Open the specified dialog without
applying the settings.
Apply: Apply the settings.
Get current value:
Restore the data before application.
Set value: Set the specified value to the spec-
ified data.
Target dialog ID This is available when [Other dialog], [Apply and change dia-
log], or [Change dialog] is selected in the “Event".
When clicking the button, select the ID for the dialog box to launch.
Data Type • [Unit data (No.)]
• Unit data (ident)
• System data
• Scene variable
• System variable
The following items (from here to “System valuable”) are avail-
able when [Set value] is selected in the “Event”.
Sets the unit specification method for targets for which to carry
out button settings.
The settings details vary depending on specification methods.
Target data No. This is available when [Unit data (No.)] is selected in the “Data
Type”.
Specifies the data to be the target for the button setting.
Enter the data number for the unit that is specified by the “Tar-
get unit No.”.
[Data reference]
button
This is available when [Unit data (No.)] is selected in the “Data
Type”.
You can select the data number directly to enter it, or you can
enter it with the [Data reference] button.
Click the [Data reference] button to select the target data in the
[Data reference] dialog box.
Data ident Sets when [Unit data (ident)] is selected in the "Data Type".
Use the unit data (identifier name) to specify the unit to be the
target for the button setting.
Ident 0
Ident 1
These are available when [System data] is selected in the
“Data Type”.
Specifies the system data to be the target for the button setting
using the identifier information 0 and identifier information 1.
(Refer to Vision System FH/FZ5 Series Macro Customize Func-
tions Programming Manual (Cat No. Z367-E1) system data list.)
Scene variable This is available when [Scene variable)] is selected in the “Data Type” .
Specifies the scene variable to be the target for the button set-
ting using the scene variable name.
System variable This is available when [System variable)] is selected in the
“Data Type”.
Specifies the system variable to be the target for the button set-
ting using the system variable name.
Set value Sets a value.
