10 Advanced Usage
10 - 38
Vision System FH/FHV/FZ5 Series User’s Manual (Z365)
(2) Loading the security settings in version from 4.20 to 4.24.
(3) Loading the security settings in version 5.00, or later.
Keeps all of the security setting items including the software version of saved in the Sensor
Controller.
Use the following procedure to delete saved user accounts and user groups settings.
Important
The current security settings are all deleted.
1 In the Main Window, select [Security settings] from the [Tool] menu.
The [Security settings] dialog box is displayed.
2 Click the [Setting] tab in the Item Tab Area.
3 Click the [Delete] button in the [Deletion of setting file] area.
The security settings are deleted and the following message is displayed.
“User info logging in was changed now. Please log in again.”
4 Click [OK].
The [Login] dialog box is displayed.
Enter the default user and password “Administrator”.
If the login dialog box is canceled, the [Security setting] dialog box is closed.
Password settings that were made in FZ4 version 4.12 or earlier can be inherited.
Important
This procedure will overwrite the current security settings.
1 In the Main Window, select [Security settings] from the [Tool] menu.
Setting item Keep Discard
Layout restrictions
Switch to ADJUST mode OK
Switch to RUN mode OK
ADJUST Control area OK
ADJUST Test measurement OK
ADJUST flow OK
ADJUST Detail result OK
ADJUST Image display OK
RUN Control area OK
RUN flow OK
RUN Detail result OK
RUN Image display OK
RUN Tool box OK
Deleting Security Settings
Transferring Old Security Settings
