10 - 41
10 Advanced Usage
Vision System FH/FHV/FZ5 Series User’s Manual (Z365)
10-4 Recording the Operation History [Oper-
ation Log]
10
10-4-1 Using the Operation Log
Important
• If the save destination of operation log does not exist or an insufficient memory is available,
the logging operation will fail. In this case, an logging error appears, refer to 11-1 Error Mes-
sages and Troubleshooting on page 11-2.
• The saving the operation log may fail at the Sensor Controller start-up because a recognition
delay for external storage happens depending on models or number of connections of exter-
nal storage.
Use the Device Information Storage Tool when the save destination of operation log is set to
external storage.
Refer to 3-6-2 Device Information Storage Tool on page 3-35.
Use the following procedure to check the current operation log function status
1 In the Main Window, select [Operation log] from the [Function] menu.
The current operation log status is displayed.
To change the current operation log status, click either [Start] or [Stop].
To close the dialog box without changing the current operation log status, click the [Cancel] but-
ton.
When the log file is set to be saved to the Controller, use the following procedure to load the file.
1 Insert an external storage device into the Controller.
2 In the Main Window, select [Save to file] from the [Function] menu.
The [Save to file] dialog box is displayed.
3 Click the [Copy files] tab.
Checking and Changing the Operation Log Status
Dialog Box When Operation Log Is Stopped Dialog Box While Operation Log Is Being Recorded
Loading an Operation Log File
