A - 33
Appendices
Vision System FH/FHV/FZ5 Series User’s Manual (Z365)
A-10 Memory Usage Guidance For Processing Items
A
Precise Calibration Approx. 660
KB
Approx. 51 MB Measurement region figure, image size,
specified calibration method.
User Data Approx. 6 KB Approx. 1 MB Number and length of calculation expres-
sions
Set Unit Data Approx. 1 KB Approx. 1 MB Length of calculation expression.
Get Unit Data Approx. 1 KB No change -
Set Unit Figure Approx. 1 KB Approx. 1 MB Number and length of calculation expres-
sions, number of figures, figure type.
Get Unit Figure Approx. 1 KB No change -
Trend Monitor Approx. 20 KB Approx. 3 MB Length of calculation expression, number
of items saved.
Image Logging Approx. 1 KB Approx. 1 MB Length of calculation expression, length of
sub-folder name, length of prefix
Image Conversion Log-
ging
Approx. 200
KB
Approx. 1 MB Length of calculation expression, length of
folder name, length of prefix
Data Logging Approx. 1 KB Approx. 1 MB Number and length of calculation expres-
sions, number and length of comments,
length of file name, length of sub-folder
name, length of prefix.
Elapsed Time Approx. 1 KB No change -
Wait Approx. 1 KB No change -
Focus Approx. 1 KB Approx. 13 MB Figure in region settings, image size.
Iris Approx. 1 KB Approx. 13 MB Figure in region settings, image size.
Parallelize Approx. 1 KB No change -
Parallelize Task Approx. 1 KB No change -
Statistics Approx. 8 KB Approx. 1 MB Number and length of calculation expres-
sions, number and length of comments.
Calibration Data Refer-
ence
Approx. 1 KB No change -
Position Data Calculation Approx. 2 KB Approx. 1 MB Number and length of calculation expres-
sions
Stage Data Approx. 1 KB No change -
Robot Data Approx. 1 KB No change -
Vision Master Calibration Approx. 82 KB Approx. 402 MB Image size.
PLC Master Calibration Approx. 81 KB Approx. 402 MB Image size.
Transfer Position Data Approx. 2 KB Approx. 1 MB Number and length of calculation expres-
sions
Calc Axis Move Approx. 4 KB Approx. 1 MB Number and length of calculation expres-
sions
Calc Axis Move by Multi-
point
Approx. 5 KB Approx. 1 MB Number and length of calculation expres-
sions
Detection Point Approx. 1 KB Approx. 1 MB Number and length of calculation expres-
sions
Camera Calibration Approx. 7 KB No change -
Data Save Approx. 1 KB Approx. 1 MB Number and length of calculation expres-
sions, number and length of comments.
Conveyor Calibration Approx. 20 KB No change -
Conditional Branch Approx. 1 KB Approx. 1 MB Number and length of calculation expres-
sions
End Approx. 1 KB No change -
DI Branch Approx. 1 KB No change -
Control Flow Normal Approx. 1 KB No change -
Item
Approximate memory usage
Main settings that affect change
of memory used
Adding to
measurement
flow
Change due to set-
tings
To Next Page
