Appendices
A - 34
Vision System FH/FHV/FZ5 Series User’s Manual (Z365)
Control Flow PLC Link Approx. 1 KB No change -
Control Flow Parallel Approx. 1 KB No change -
Control Flow Fieldbus Approx. 1 KB No change -
Selective Branch Approx. 3 KB Approx. 1 MB Length of conditional expression, number
and length of branch setting comments.
Data Output Approx. 14 KB Approx. 1 MB Communication module settings, number
and length of calculation expressions,
number and length of comments.
Parallel Data Output Approx. 1 KB Approx. 1 MB Communication module settings, number
and length of calculation expressions,
number and length of comments.
Parallel Judgement Out-
put
Approx. 1 KB Approx. 1 MB Number and length of calculation expres-
sions, number and length of comments.
Fieldbus Data Output Approx. 6 KB Approx. 1 MB Communication module settings, number
and length of calculation expressions,
number and length of comments.
Result Display Approx. 1 KB Approx. 1 MB Result display type, number of results dis-
played, number and length of calculation
expressions, number and length of char-
acters.
Display Image File Approx. 1 KB Approx. 1 MB Number and length of file names.
Display Last NG Image Approx. 3 KB Approx. 1 MB Number and length of calculation expres-
sions, number and length of comments.
Conveyor Panorama
Display
Approx. 491
KB
No change -
Item
Approximate memory usage
Main settings that affect change
of memory used
Adding to
measurement
flow
Change due to set-
tings
