3 - 19
3 Basic Operations
Vision System FH/FHV/FZ5 Series User’s Manual (Z365)
3-2 Basic Knowledge about Operations
3
3-2-6 Setting Figures
 Circumference
• Using numbers for setting
The setting area consists of two windows below. Click the [1] or [2] on the right side of the window to
select the setting item.
• Image selection status • Dimension Adjustment
Drag the points.
• Example) When enlarging the entire cir-
cumference
Drag a point on the outer circle.
• Example) When adjusting the width of the
circumference
Drag a point on the inner circle.
Points are displayed on
the top, bottom, left,
and right of both the
inner and outer circles.
