3 Basic Operations
3 - 30
Vision System FH/FHV/FZ5 Series User’s Manual (Z365)
Additional Information
The Memory state window can be displayed from Measurement Manager Bar, as well as taking
above steps starting from System information.
Refer to 3-4 Checking the Memory Consumption and Percentage of Memory Used on page 3-
31.
 Regarding [Firmware upgrade] button
Click the [Firmware upgrade] button only when launch the Firmware upgrade tool.
Do not click it except when launch this tool.
If you accidentally click [Firmware upgrade] button, a dialog which informs you need to end the tool.
In this case, click [Cancel], and then back to a window to confirm the system information.
Important
If you clock the [Firmware upgrade] button without insert external storage which saved data of
Firmware upgrade tool, a dialog appears indicates you should end the measurement applica-
tion.
When [Yes] or [No] are clicked, the measurement application finishes.
When you want to re-launch the measurement application, turn OFF the power source once,
and then turns ON.
Image value is too large. Modify the Scenes and reduce the filter units.
Replace some filtering processing into one advanced filter.
Or lower the camera resolution.
Status Countermeasures
