Definitions of Basic Terms
Vision System FH/FHV/FZ5 Series User’s Manual (Z365)
Definitions of Basic Terms
Term Definition
FH Series All FH series model names as follows:
FH-1, FH-1-, FH-2, FH-2-, FH-3,
FH-3-, FH-5, FH-5-, FH-L, FH-L-
FH-1000 series All FH-1 series model names as follows:
FH-1, FH-1-
FH-2000 series All FH-2 series model names as follows:
FH-2, FH-2-
FH-3000 series All FH-3 series model names as follows:
FH-3, FH-3-
FH-5000 series All FH-5 series model names as follows:
FH-5, FH-5-
FH-L series All FH-L series model names as follows:
FH-L, FH-L-
FZ5 series All FZ series name shows the following:
FZ5-6, FZ5-6-, FZ5-8, FZ5-8-, FZ5-11, FZ5-11-,
FZ5-12, FZ5-12-, FZ
5-L35, FZ5
-L35-
FZ5-600 series All FZ5-6series name the following:
FZ5-6, FZ5-6-
FZ5-800 series All FZ5-8series name the following:
FZ5-8, FZ5-8-
FZ5-1100 series All FZ5-11series name the following:
FZ5-11, FZ5-11-
FZ5-1200 series All FZ5-12series name the following:
FZ5-12, FZ5-12-
FZ5-L series All FZ5-L35 series name the following:
FZ5-L35, FZ5-L35-
Sensor Controller It is a generic name of FH/FZ5 series. For FHV series, it has the same meaning as
smart camera.
measurement flow
(abbreviated as “flow”)
A continuous flow of measurement processing. A measurement flow consists of a
scene created from a combination of processing items.
measurement processing
Executing processing items for inspections and measurements.
Measurement ID Information of time when the sensor controller receives the measurement trigger and
the line no.
Format of measurement ID: YYYY-MM-DD_HH-MM-SS-XXXX
YYYY: Year (4 digits)
MM: Month
DD: Date
HH: Hour
MM: Minute
SS: Second
XXXX: Millisecond
Example:
Measured time: 12/24/2007, 11:10:25.500:
Line: 0
Measurement ID: 2007-12-24_11-10-25-5000
