Remove the Motherboard Assembly
12.
Remove the following reusable components from the motherboard and install
them on to the replacement motherboard.
■
DDR4 DIMMs
See “Identify and Remove a Faulty DIMM” on page 81 and “Install a
DIMM” on page 84.
Note - Install the DDR4 DIMMs only in the slots (connectors) from which they were
removed. Performing a one-to-one replacement of DIMMs significantly reduces the
possibility that DIMMs will be installed in the wrong slots. If you do not reinstall the
DIMMs in the same slots, server performance might be reduced and some DIMMs might
not be used.
■
USB flash drives
See “Remove the Internal USB Flash Drive” on page 93 and “Install the Internal USB
Flash Drive” on page 94.
13.
Remove the processors from the failed motherboard.
See “Remove a Processor” on page 100.
14.
Remove the processor socket covers from the replacement motherboard and
install the processors.
a.
Disengage the processor ILM assembly hinge lever on the right side of
the processor socket (viewing the server from the front) by pushing down
150 Oracle Exadata Storage Server X5-2 High Capacity Service Manual • January 2018
