Setting up Compax3
192-120114 N5 C3I22T11 June 2008 157
Example: Electronic gearbox with position detection via encoder
The reference to the master axis is established via the increments per revolution
and the travel path per revolution of the master axis (corresponds to the circumfe-
rence of the measuring wheel).
That is:
Master_I Travel Distance per Master Axis revolution
(M_Units/rev)
MasterPos =
I_M
*
Travel Distance per Master Axis revolution -
Denominator
(1)
MasterPos: Master Position
Master_I: master increments read in
I_M: Increments per revolution of the master axis
Encoder with 1024 increments per master revolution and a circumference of the
measuring wheel of 40mm.
Travel path per revolution of the master axis numerator = 40
Travel path per revolution of the master axis denominator = 1
Increments per revolution of the master axis = 1024
Reference system of Slave axis: Unit of measure [mm]
Travel path per revolution numerator = 1
Travel path per revolution denominator = 1
Gearing numerator = 2
Gearing denominator = 1
This results in the following interrelations:
If the measuring wheel moves by 40mm (1 master revolution), the slave axis will
move by 80mm.
Gearing numera-
tor
Slave unit = MasterPos *
Gearing denomi-
nator
(2)
(1) set into (2) and with numerical values results with 1024 increments read in (=1
Master revolution):
1
40mm 2Slave unit = 1024 *
1024
*
1
*
1
= 80mm
Master - Position = +40mm => Slave - Position = +80mm
Reference to master
axis
External signal
source
Settings:
Configuration wi-
zard:
Gearing:

Parker Compax3 Series Specifications

General

Enclosure Rating	IP20
Control Modes	Speed, Torque, Position
Communication Interfaces	CANopen, EtherCAT
Feedback Options	Incremental Encoder, Resolver
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Cooling Method	Forced Air, Natural Convection
Relative Humidity	5 to 85 %, non-condensing
Operating Temperature	0 to +45 °C (derating may apply above 40°C)
