DeviceNet characteristic data
DeviceNet
Predefined Master/Slave Connection Set
Standard 2.0 Group-2-Slave
Fieldbus I/O Data or Process Data (Pol-
led, COS/Cyclic I/O and Bit Strobe)
Implemented object classes
Identify, Message Router, DeviceNet,
Assembly, Connection, Acknowledge
Handler
Baud rate [kBit/s]
125, 250, 500
permissible cable length
up to 500m on 125Bit/s,
up to 200m on 250Bit/s,
up to 100m on 500Bit/s,
Max. number of nodes
63 Slave
Insulation
Isolated Device Physical Layer
EDS file
C3_DeviceNet.EDS
Conformance (file in the Internet)
Statement of Conformance
http://www.compax3.de/C3_DeviceNet_S
tatement_of_
Conformance.pdf
Further information:
Application example
(C3I22_DeviceNet.ZIP) on the Compax3
CD in the "\Examples" directory
