Setting up Compax3
C3I12T11
114
192-120113 N08 C3I12T11 - December 2010
MN-M 23...26: Direction reversal switches on the positive side
Without motor zero point, with direction reversal switches
23
24
25
26
24
2623
26
25
25
23
24
1
2
1: Logic state of the home switch
2: Logic state of the direction reversal switch
MN-M 27...30: Direction reversal switches on the negative side
Without motor zero point, with direction reversal switches
30
30
30
29
29
29
28
28
28
27
27
27
1
2
1: Logic state of the home switch
2: Logic state of the direction reversal switch
