Compax3 - Objects
C3I12T11
318
192-120113 N08 C3I12T11 - December 2010
Object-
No.
Object name Object Acc
ess
688.1 C3.StatusCurrent_Reference Status of setpoint current RMS (torque forming) ro
688.18 C3.StatusCurrent_ReferenceDINT Target current r.m.s. ro
681.6 C3.StatusSpeed_Error Status control deviation of speed ro
681.11 C3.StatusSpeed_FeedForwardSpeed Status speed feed forward ro
681.21 C3.StatusSpeed_LoadControlFiltered Speed of the load feedback (filtered) ro
2210.17 C3.SpeedController_ActualBandwidth Replacement time constant for the velocity control ro
2210.5 C3.SpeedController_I_Part_Gain Weighting "I" term r/w
2210.4 C3.SpeedController_P_Part_Gain P term quantifier r/w
2120.7 C3.SpeedObserver_DisturbanceAdditionEnable Switch to enable disturbance compensation r/w
2120.5 C3.SpeedObserver_DisturbanceFilter Time constant disturbance filter r/w
2120.1 C3.SpeedObserver_TimeConstant Rapidity of the speed monitor r/w
682.5 C3.StatusAccel_Actual Status of actual acceleration unfiltered ro
682.6 C3.StatusAccel_ActualFilter Status of filtered actual acceleration ro
682.4 C3.StatusAccel_DemandValue Status demand acceleration ro
682.7 C3.StatusAccel_FeedForwardAccel Status acceleration feed forward ro
690.5 C3.StatusAutocommutation_Itterations Current increase steps automatic commutation ro
688.2 C3.StatusCurrent_Actual Status of actual current RMS (torque producing) ro
688.19 C3.StatusCurrent_ActualDINT Actual current r.m.s. ro
688.8 C3.StatusCurrent_ControlDeviationIq Status of control deviation of current control RMS ro
688.31 C3.StatusCurrent_DecouplingVoltageUd Signal decoupling of direct current controller ro
688.32 C3.StatusCurrent_FeedForwardbackEMF Signal EMC feedforward ro
688.14 C3.StatusCurrent_FeedForwordCurrentJerk Status of current & jerk feedforward ro
688.13 C3.StatusCurrent_ReferenceJerk Status of demand jerk setpoint generator ro
688.11 C3.StatusCurrent_ReferenceVoltageUq Status of current control control signal ro
688.22 C3.StatusCurrent_ReferenceVoltageVector Provided voltage pointer ro
688.30 C3.StatusCurrent_VoltageUd Provided voltage of direct current controller ro
688.29 C3.StatusCurrent_VoltageUq Provided voltage of quadrature current controller ro
683.2 C3.StatusDevice_ActualDeviceLoad Status of device load ro
683.3 C3.StatusDevice_ActualMotorLoad Status of long-term motor load ro
683.5 C3.StatusDevice_ObservedDisturbance Status of observed disturbance ro
692.4 C3.StatusFeedback_EncoderCosine Status of analog input cosine ro
692.3 C3.StatusFeedback_EncoderSine Status of analog input sine ro
692.2 C3.StatusFeedback_FeedbackCosineDSP Status of cosine in signal processing ro
692.1 C3.StatusFeedback_FeedbackSineDSP Status of sine in signal processing ro
692.5 C3.StatusFeedback_FeedbackVoltage[Vpp] Status of feedback level ro
680.5 C3.StatusPosition_Actual Status actual position ro
680.13 C3.StatusPosition_ActualController Status actual position without absolute reference ro
680.12 C3.StatusPosition_DemandController
Status demand position without absolute
reference
ro
680.4 C3.StatusPosition_DemandValue Status demand position ro
680.6 C3.StatusPosition_FollowingError Status of tracking error ro
680.23 C3.StatusPosition_LoadControlActual Actual position of the load ro
680.20 C3.StatusPosition_LoadControlDeviation Position difference load-motor (unfiltered) ro
680.22 C3.StatusPosition_LoadControlDeviationFiltered Position difference load-motor (filtered) ro
681.5 C3.StatusSpeed_Actual Status actual speed unfiltered ro
681.9 C3.StatusSpeed_ActualFiltered Status actual speed filtered ro
681.12 C3.StatusSpeed_ActualScaled Filtered actual speed ro
681.13 C3.StatusSpeed_DemandScaled Setpoint speed of the setpoint generator ro
681.10 C3.StatusSpeed_DemandSpeedController Status demand speed controller input ro
681.4 C3.StatusSpeed_DemandValue Status demand speed of setpoint generator ro
681.25 C3.StatusSpeed_NegativeLimit Negative speed limit currently effective ro
681.24 C3.StatusSpeed_PositiveLimit Positive speed limit currently effective ro
684.2 C3.StatusTemperature_Motor Status of motor temperature ro
1903.1 C3Array.Col03_Row01 variable Column 3 Row 1 r/w
684.1 C3.StatusTemperature_PowerStage Status of power output stage temperature ro
685.3 C3.StatusVoltage_AnalogInput0 Status of analog input 0 ro
685.4 C3.StatusVoltage_AnalogInput1 Status of analog input 1 ro
685.1 C3.StatusVoltage_AuxiliaryVoltage Status of auxiliary voltage ro
685.2 C3.StatusVoltage_BusVoltage Status DC bus voltage ro
