Parker Compax3 User Manual

Technical Characteristics
C3I12T11
376
192-120113 N08 C3I12T11 - December 2010
Output data Compax3Mxxx at 3*230VAC
Device type Compax3 M050D6 M100D6 M150D6 M300D6
Input voltage
325VDC ±10%
Output voltage
3x 0-230V (0...500Hz)
Nominal output current
5Arms 10Arms 15Arms 30Arms
Pulse current for 5s*
10Arms 20Arms 30Arms 60Arms
Power
2kVA 4kVA 6kVA 12kVA
Switching frequency
8kHz 8kHz 8kHz 8kHz
Power loss for In
70W+** 90W+** 120W+** 270W+**
*Electrical turning frequency for pulse current: f>5 Hz; with an electrical turning frequency of f<5 Hz, the
maximum pulse current time is 100ms
** Maximum additional losses with option card 5 W.
Output data Compax3Mxxx at 3*400VAC
Device type Compax3 M050D6 M100D6 M150D6 M300D6
Input voltage
565VDC ±10%
Output voltage
3x 0-400V (0...500Hz)
Nominal output current
5Arms 10Arms 15Arms 30Arms
Pulse current for 5s*
10Arms 20Arms 30Arms 60Arms
Power
3.33kVA 6.66kVA 10kVA 20kVA
Switching frequency
8kHz 8kHz 8kHz 8kHz
Power loss for In
70W+** 90W+** 120W+** 270W+**
*Electrical turning frequency for pulse current: f>5 Hz; with an electrical turning frequency of f<5 Hz, the
maximum pulse current time is 100ms
** Maximum additional losses with option card 5 W.
Output data Compax3Mxxx at 3*480VAC
Device type Compax3 M050D6 M100D6 M150D6 M300D6
Input voltage
680VDC ±10%
Output voltage
3x 0-480V (0...500Hz)
Nominal output current
4Arms 8Arms 12.5Arms 25Arms
Pulse current for 5s*
8Arms 16Arms 25Arms 50Arms
Power
3.33kVA 6.66kVA 10kVA 20kVA
Switching frequency
8kHz 8kHz 8kHz 8kHz
Power loss for In
70W+** 90W+** 120W+** 270W+**
*Electrical turning frequency for pulse current: f>5 Hz; with an electrical turning frequency of f<5 Hz, the
maximum pulse current time is 100ms
** Maximum additional losses with option card 5 W.

Parker Compax3 Specifications

General

Protection Class	IP20
Control Modes	Torque, Speed, Position
Feedback Options	Incremental encoder, Absolute encoder, Resolver
Communication Interfaces	CANopen, EtherCAT, Profinet
Safety Features	STO (Safe Torque Off), SS1 (Safe Stop 1), SOS (Safe Operating Stop)
Input Voltage	200-480 VAC
Relative Humidity	5% to 85% (non-condensing)
Shock Resistance	According to EN 60068-2-27
Operating Temperature	0°C to +40°C
