Parker Compax3 User Manual

Parker EME
Technical Characteristics
192-120113 N08 C3I12T11 - December 2010
377
Output data Compax3Hxxx at 3*400VAC
Controller type
H050V4
H090V4
H125V4
H155V4
Output voltage
3x 0-400V
Nominal output current
50Arms 90Arms 125Arms 155Arms
Pulse current for 5s *
75Arms 135Arms 187.5Arms 232.5Arms
Power
35kVA 62kVA 86kVA 107kVA
Switching frequency
8kHz 8kHz 8kHz 8kHz
Power loss for In
880W 900W 1690W 1970W
* during low speeds, the overload time is reduced to 1s. Limit:
< 2.5 electric rev/s (= actual revolutions/s * number of pole pairs) resp. >2.5 pitch/s
Output data Compax3Hxxx at 3*480VAC
Controller type
H050V4
H090V4
H125V4
H155V4
Output voltage
3x 0-480V
Nominal output current
43Arms 85Arms 110Arms 132Arms
Pulse current for 5s*
64.5Arms 127.5Arms 165Arms 198Arms
Power
35kVA 70kVA 91kVA 109kVA
Switching frequency
8kHz 8kHz 8kHz 8kHz
Power loss for In
850W 1103W 1520W 1800W
* during low speeds, the overload time is reduced to 1s. Limit:
< 2.5 electric rev/s (= actual revolutions/s * number of pole pairs) resp. >2.5 pitch/s

Parker Compax3 Specifications

General

Protection Class	IP20
Control Modes	Torque, Speed, Position
Feedback Options	Incremental encoder, Absolute encoder, Resolver
Communication Interfaces	CANopen, EtherCAT, Profinet
Safety Features	STO (Safe Torque Off), SS1 (Safe Stop 1), SOS (Safe Operating Stop)
Input Voltage	200-480 VAC
Relative Humidity	5% to 85% (non-condensing)
Shock Resistance	According to EN 60068-2-27
Operating Temperature	0°C to +40°C
