Parker Compax3 User Manual

Technical Characteristics
C3I12T11
384
192-120113 N08 C3I12T11 - December 2010
Size / weight Compax3S
Controller type
Dimensions
HxWxD [mm]
Weight [kg]
Compax3S025V2
191 x 84 x 172 2.0
Compax3S063V2
191 x 100 x 172 2.5
Compax3S015V4
248 x 84 x 172 3.1
Compax3S100V2
248 x 115 x 172 4.3
Compax3S150V2
248 x 158 x 172 6.8
Compax3S038V4
248 x 100 x 172 3.5
Compax3S075V4
248 x 115 x 172 4.3
Compax3S150V4
248 x 158 x 172 6.8
Compax3S300V4
380 x 175 x 172 10.9
Minimum mounting distance: 15mm at the sides, above & below 100mm
Protection type IP20
Drawings, Mounting (see on page 68, see on page 74)
Size / weight PSUP/Compax3M
Device type
Dimensions HxWxD
[mm]
Weight
[kg]
PSUP10D6
360 x 50 x 263 3.95
PSUP20D6 & PSUP30D6
360 x 100 x 263 6.3
Compax3M050D6
360 x 50 x 263 3.5
Compax3M100D6
360 x 50 x 263 3.6
Compax3M150D6
360 x 50 x 263 3.6
Compax3M300D6
360 x 100 x 263 5.25
Protection type IP20
Size / weight Compax3H
Mounting (see on page 68, see on page 74)
Controller type
Dimensions
HxWxD [mm]
Weight [kg]
Compax3H050V4
453 x 252 x 245 17.4
Compax3H090V4
668.6 x 257 x 312 32.5
Compax3H125V4
720 x 257 x 355 41
Compax3H155V4
720 x 257 x 355 41
Protection class IP20 when mounted in a control cabinet (not for
Compax3H1xxxV4)
Mounting

Parker Compax3 Specifications

General

Protection Class	IP20
Control Modes	Torque, Speed, Position
Feedback Options	Incremental encoder, Absolute encoder, Resolver
Communication Interfaces	CANopen, EtherCAT, Profinet
Safety Features	STO (Safe Torque Off), SS1 (Safe Stop 1), SOS (Safe Operating Stop)
Input Voltage	200-480 VAC
Relative Humidity	5% to 85% (non-condensing)
Shock Resistance	According to EN 60068-2-27
Operating Temperature	0°C to +40°C
