Parker Compax3 User Manual

Parker EME
Technical Characteristics
192-120113 N08 C3I12T11 - December 2010
383
Ballast resistors for Compax3
Ballast resistor (see on page
345)
Device
Rated output
BRM08/01 (100Ω)
Compax3S025V2
Compax3S015V4
Compax3S038V4
60 W
BRM05/01 (56
Ω
)
Compax3S063V2
Compax3S075V4
180 W
BRM05/02 (56Ω)
Compax3S075V4 570 W
BRM10/01 (47
Ω
)
Compax3S150V4 570 W
BRM10/02 (470
Ω
)
Compax3S150V4 1500 kW
BRM04/01 (15
Ω
)
Compax3S150V2
Compax3S300V4
PSUP20D6
570 W
BRM04/02 (15
Ω
)
Compax3S150V2
Compax3S300V4
PSUP20D6
740 W
BRM04/03 (15Ω)
Compax3S300V4
PSUP20D6
1500 W
BRM09/01 (22
Ω
)
Compax3S100V2 570 W
BRM11/01 (27
Ω
)
Compax3H0xxV4 3500 W
BRM13/01 (30
Ω
)
PSUP10D6
PSUP20D6**
500 W
BRM14/01 (15Ω)
PSUP10D6*
PSUP20D6
500 W
BRM12/01 (18
Ω
)
Compax3H1xxV4 4500 W
*for PSUP10D6 2x15Ω in series
**for PSUP20D6 2x30Ω parallel

Parker Compax3 Specifications

General

Protection Class	IP20
Control Modes	Torque, Speed, Position
Feedback Options	Incremental encoder, Absolute encoder, Resolver
Communication Interfaces	CANopen, EtherCAT, Profinet
Safety Features	STO (Safe Torque Off), SS1 (Safe Stop 1), SOS (Safe Operating Stop)
Input Voltage	200-480 VAC
Relative Humidity	5% to 85% (non-condensing)
Shock Resistance	According to EN 60068-2-27
Operating Temperature	0°C to +40°C
