Parker Compax3 User Manual

Technical Characteristics
C3I12T11
382
192-120113 N08 C3I12T11 - December 2010
Braking operation Compax3S0xxV2 1AC
Controller type
S025V2
S063V2
Capacitance / storable energy
560µF / 15Ws 1120µF / 30Ws
Minimum braking- resistance
100Ω 56Ω
Recommended nominal power rating
20 ... 60W 60 ... 180W
Maximum continuous current
8A 15A
Braking operation Compax3S1xxV2 3AC
Controller type
S100V2
S150V2
Capacitance / storable energy
780µF / 21Ws 1170µF / 31Ws
Minimum braking- resistance
22Ω 15Ω
Recommended nominal power rating
60 ... 450W 60 ... 600W
Maximum continuous current
20A 20A
Braking operation Compax3SxxxV4 3AC
Controller type
S015V4
S038V4
S075V4
S150V4
S300V4
Capacitance / storable energy
400V / 480V
235µF
37 / 21 Ws
235µF
37 / 21 Ws
470µF
75 / 42 Ws
690µF
110 / 61 Ws
1230µF
176 / 98 Ws
Minimum braking- resistance
100Ω 100Ω 56Ω 33Ω 15Ω
Recommended nominal power
rating
60 ...
100W
60 ... 250W
60 ... 500
W
60 ... 1000
W
60 ... 1000
W
Maximum continuous current
10A 10A 15A 20A 30A
Braking operation Compax3MxxxD6 (axis controller)
Device type
Compax3
M050
M100
M150
M300
Capacity/
storable energy
110µF/
18Ws at 400V
10Ws at 480V
220µF/
37Ws at 400V
21Ws at 480V
220µF/
37Ws at 400V
21Ws at 480V
440µF/
74Ws at 400V
42Ws at 480V
Braking operation of Compax3HxxxV4
Controller type
H050V4
H090V4
H125V4
H155V4
Capacitance / storable energy
400V / 480V
2600 µF
602 / 419 Ws
3150 µF
729 / 507 Ws
5000 µF
1158 / 806 Ws
5000 µF
1158 / 806 Ws
Minimum braking- resistance
24 Ω 15 Ω 8 Ω 8 Ω
Maximum continuous current
11 A 17 A 31 A 31 A

Parker Compax3 Specifications

General

Protection Class	IP20
Control Modes	Torque, Speed, Position
Feedback Options	Incremental encoder, Absolute encoder, Resolver
Communication Interfaces	CANopen, EtherCAT, Profinet
Safety Features	STO (Safe Torque Off), SS1 (Safe Stop 1), SOS (Safe Operating Stop)
Input Voltage	200-480 VAC
Relative Humidity	5% to 85% (non-condensing)
Shock Resistance	According to EN 60068-2-27
Operating Temperature	0°C to +40°C
