Connect+® Series Operator Guide
14. Select Tape to print the first horizontal test pattern.
a. Select the Pattern number: field.
b. Enter the number of the best aligned pattern.
c. Select OK.
d. Select Next to continue.
15. Repeat step 14 to print the second horizontal test pattern.
16. If the alignment was successful, a message appears indicating that the print heads have
been aligned to print on envelopes and tape. Select Done.
Envelope Alignment Only
1. Enter the length of your envelope.
a. Use the + and - buttons to adjust the length measurement. The minimum and max-
imum lengths allowed are displayed on the screen.
b. Select Next to continue.
2.
Select the location on the envelope where most full color graphics are printed.
NOTE: Do not change this setting unless instructed to do so.
l
Select Left if most full color graphics are printed as part of the return address.
l
Select Center (recommended) if most full color graphics are printed as part of a
graphic or text message.
l
Select Right if most full color graphics are printed as part of a permit.
Select Next to continue.
3. Place an envelope on the feed deck and select Start to print the vertical test pattern.
4. Select the Pattern number: field.
a. Enter the number of the best aligned pattern.
b. Select OK.
c. Select Next to continue.
5. Repeat steps 3 and 4 to print the second vertical test pattern.
6.
If the alignment was successful, a message appears indicating that the print heads have
200
SV62250 Rev. G
