Polaris RANGER XP 1000 2018-2019

3
9929399 R01 - 2018-2019 RANGER XP/ CREW 900/1000 Service Manual
© Copyright Polaris Industries Inc.
3.117
HVAC SYSTEM
GENERAL INFORMATION - HVAC
HVAC SYSTEM FASTENER TORQUES
ITEM
TORQUE VALUE
Alternator Mounting Fasteners 37 lb-ft (50 Nm)
Alternator Cover Fasteners
48 lb-in (5.4 Nm)
Compressor Low Pressure Hose 25 lb-ft (34 Nm)
Compressor High Pressure Hose 18 lb-ft (24 Nm)
Compressor Mounting Fasteners 37 lb-ft (50 Nm)
Compressor Oil Drain Plug 10 ft-lb (14 Nm)
HVAC Timing Wheel Fasteners 9 lb-ft (12 Nm)
HVAC Cover Mount Fasteners
9 lb-ft (12 Nm)
HVAC Drive Pulley Fastener
44 lb-ft (60 Nm) +
180°
Upper Condenser Hose 18 ft-lb (24 Nm)
Lower Condenser / Receiver-
Drier Hose
12 ft-lb (16 Nm)
Condenser Upper Mounting Bolt 14 ft-lb (19 Nm)
Condenser Lower Mounting
Bolts
8 ft-lb (11 Nm)
HPCO Switch
6 ft-lb (8 Nm)
Heater / Evaporator Unit
Mounting Fasteners
10 lb-ft (14 Nm)
Expansion Valve High / Low
Pressure Hoses
12 ft-lb (16 Nm)
Expansion Valve Tubes 22 ft-lb (30 Nm)
Heater Valve Fasteners
8 lb-ft (11 Nm)
SPECIAL TOOLS - HVAC
TOOL DESCRIPTION PART NUMBER
Refrigerant Recovery / Recycle
/Recharging Machine
PU-51021
Recharge Service Kit (for PU-
51021)
PU-51021-1
HVAC Belt Tool PU-52087
Crankshaft Pulley Holder
PU-52254
Bosch Automotive Service Solutions: 1-800-345-2233 or
http://polaris.service-solutions.com.
ENGINE / COOLING / HVAC SYSTEM
