6.14
9929399 R01 - 2018-2019 RANGER XP/ CREW 900/1000 Service Manual
© Copyright Polaris Industries Inc.
25.Install the PVT inner clutch cover, drive clutch, driven
clutch, drive belt and outer clutch cover. Refer to PVT
Assemblypage 5.10 procedure.
26.Install both rear drive shafts. Refer to “Rear Drive
Shaft Installation”page 7.38 procedure.
27.Install the front propshaft. Refer to “Front Propshaft
Removal / Installation”page 7.9 procedure.
28.Safely lower the vehicle.
29.Install the rear cargo box assembly. Refer to “Cargo
Box Installation”page 10.27 procedure.
NOTICE
Be sure to connect the tail light harness upon
installation.
30.Connect the (-) negative battery cable.
31.If the transmission lubricant was drained for service,
fill the transmission with the specified amount of
Polaris AGL. Refer to “Transmission
Lubrication”page 2.29.
FLUID CAPACITY
Recommended Transmission Lubricant: AGL
(PN: 2878068) (Quart)
Capacity: 41 oz. (1200 ml)
TRANSMISSION MOUNTING TORQUE
VALUES
TRANSMISSION
