Polaris RANGER XP 1000 2018-2019

5
9929399 R01 - 2018-2019 RANGER XP/ CREW 900/1000 Service Manual
© Copyright Polaris Industries Inc.
5.3
SERVICE SPECIFICATIONS - PVT SYSTEM
PART
DESCRIPTION
SERVICE
SPECIFICATION
SERVICE
LIMIT
Drive Clutch
Spring Part
Number
7044111
-
Drive Clutch
Spring Color
White / Blue
-
Drive Clutch
Spring Free
Length
3.905 in (9.92
cm)
-
Drive Clutch
Button to Tower
Clearance
000-.005”
-
Drive Clutch
Shaft Diameter
1.374” (34.89
mm)
1.372” (34.86
mm)
Vespel® Thrust
Washer
Thickness
0.030” (0.76 mm) 0.025” (0.64
mm)
PVT SYSTEM
