5.8
9929399 R01 - 2018-2019 RANGER XP/ CREW 900/1000 Service Manual
© Copyright Polaris Industries Inc.
PVT COVERS AND DUCTING COMPONENTS - HIGH LIFTER
PART # DESCRIPTION PART # DESCRIPTION PART # DESCRIPTION
1 OUTER CLUTCH COVER
7
CLAMP, NARROW 13 CLAMP, WORM DRIVE
2 O-RING 8 SCREW 14 DUCT, CLUTCH INLET
3 PLUG, DRAIN 9 SCREW 15 DUCT, CLUTCH OUTLET
4 SEAL, OUTER 10 INNER CLUTCH COVER 16 COVER, INTAKE BOTTOM
5
SEAL, COVER 11 HOSE, CLUTCH AIR INLET 17 COVER, INTAKE TOP
6 ASM, BOLT / WASHER 12 HOSE, CLUTCH AIR
OUTLET
PVT SYSTEM
