Polaris RANGER XP 1000 2018-2019

10.14
9929399 R01 - 2018-2019 RANGER XP/ CREW 900/1000 Service Manual
© Copyright Polaris Industries Inc.
CAB FRAME SERVICE
CAB FRAME / HEADRESTS / SIDE NETS ASSEMBLY VIEW
CAB FRAME / HEADRESTS / SIDE NETS ASSEMBLY VIEW
*Vehicles with bucket seats and doors do not include Side Nets, Hip Bolster, or Head Rests.
REF DESCRIPTION REF DESCRIPTION REF DESCRIPTION
q
FRAME, CAB REAR
i
HANDLE, GRAB
h
PLUG, FENDER
w
FRAME, CAB FRONT LH
o
HEADREST
j
SCREW
e
FRAME, CAB FRONT RH
a
SCREW
k
RIVET
r
HIP BOLSTER
s
NUT, FLANGE
l
BOLT
t
HIP BOLSTER, RH
d
SCREW
1(
WASHER
y
HIP BOLSTER, LH
f
NUT, NYLOK
2)
BOLT
u
PLATE, WINDSHIELD MOUNT
g
SCREW
2!
NUT
BODY / FRAME
