Polaris RANGER XP 1000 2018-2019

10
9929399 R01 - 2018-2019 RANGER XP/ CREW 900/1000 Service Manual
© Copyright Polaris Industries Inc.
10.13
REF DESCRIPTION REF DESCRIPTION REF DESCRIPTION
q
ASM, SEAT BOTTOM
o
ASM, SEAT CENTER
k
CLAMP
w
BRACKET, SEAT HINGE
a
GROMMET
l
SCREW
e
SCREW
s
ASM, SEAT BELT CENTER
1(
NUT
r
PIN, SEAT LATCH
d
ASM, SEAT BELT
2)
NUT
t
ASM, SEAT BOTTOM
f
COVER, SEAT BELT MNT
2!
BUCKLE, SEAT BELT
PSNGR
y
BRACKET, SEAT HINGE DBL
g
CAP, BOLT HEAD
2@
BUCKLE, SEAT BELT
DRIVER
u
ASM, SEAT BACK PSNGR
h
WASHER
2#
BUCKLE, SEAT BELT
SWITCH
i
BRACKET, SEAT HINGE
j
PAD
BODY / FRAME
