Polaris RANGER XP 1000 2018-2019

10.26
9929399 R01 - 2018-2019 RANGER XP/ CREW 900/1000 Service Manual
© Copyright Polaris Industries Inc.
CARGO BOX SUPPORT ASSEMBLY VIEW
REF PART DESCRIPTION REF PART DESCRIPTION
q
SUPPORT, BOX
s
BOLT
w
LATCH, BOX
d
SCREW
e
BUMPER, BOX
f
SCREW
r
BUSHING, BOX LATCH
g
SCREW
t
SPRING, LATCH
h
NUT, FLANGE
y
SPRING, LATCH
j
CLIP, HITCHPIN
u
SCREW
k
PIN, CLEVIS
i
RIVET
l
WASHER
o
NUT
1(
HANDLE, BOX LATCH
a
SHOCK, BOX DUMP
BODY / FRAME
