Polaris RANGER XP 1000 2018-2019

3
9929399 R01 - 2018-2019 RANGER XP/ CREW 900/1000 Service Manual
© Copyright Polaris Industries Inc.
3.119
HVAC ASSEMBLY VIEW
REF
DESCRIPTION NOTES
1
Compressor
2 Condenser
3
Receiver / Drier
4
Pressure Relief Valve
5 Expansion Valve
6
Heater / Evaporator Unit
7
Cabin Air Filter
8 Electronic De-icing Thermostat (EDT)
9
A/C Charge Port
10 Heater Valve
11
High Pressure Cut-Out Switch (HPCO)
12
Compressor Drive Belt
13 Alternator
14 Alternator Cover
15 Alternator Air Inlet
16 Alternator Air Outlet
ENGINE / COOLING / HVAC SYSTEM
