SERVICE SPECIFICATIONS - MAINTENANCE
GENERAL SPECIFICATIONS
ITEM
STANDARD SERVICE LIMIT
Battery Type / CCA
Johnson Controls / 575 CCA / 12V
-
Brake Pad Thickness, Front
0.297 ± .007" (7.54 ± .178 mm) 0.150" (3.8 mm)
Brake Disc Thickness, Front
0.188" ( 4.78 mm) 0.170" (4.32 mm)
Brake Pad Thickness, Rear
0.298 ± .007" (7.56 ± .178 mm) 0.150" (3.8 mm)
Brake Disc Thickness, Rear
0.188" (4.78 mm) 0.170" (4.32 mm)
Fuel Pressure (KOEO) 58 ± 2 psi (400 ± 14 kPa) -
Idle Speed
1250 ± 50 RPM
-
Oil Pressure (Minimum)
10 PSI @ 1200 RPM (Minimum)
40 PSI @ 7000 RPM (Minimum)
-
Spark Plug Type / Gap NGK MR7F / 0.030 in (0.75 mm) -
Tire Pressure (Base / CREW)
Front: 10 psi (69 kPa) / 14 psi (97 kPa)
Rear: 12 psi (83 kPa) / 16 psi (110 kPa)
-
Tire Tread Depth (Minimum) - 0.118 in (3 mm)
Cylinder Leakage -
20%
Intake Valve Clearance (Cold) 0.006 ± .002 in (0.15 ± 0.05 mm) -
Exhaust Valve Clearance (Cold) 0.010 ± .002 in (0.25 ± 0.05 mm) -
Wheel Toe Out
1/8-1/4 in (3.2-6.4 mm) -
FLUID SPECIFICATIONS
ITEM
FLUID TYPE CAPACITY
Engine Oil PS-4 2W-50 Synthetic 2.5 Qt (2.4 L)
Transmission Oil AGL Gearcase Lubricant 41 oz (1200 mL)
Front Gearcase
Demand Drive Fluid
6.75 oz (200 mL)
Engine Coolant 50 / 50 Extended Life Antifreeze 5 Qt (4.7 L)
Fuel
87 Octane (minimum) 10 Gal (37.8 L)
Brake / Clutch Fluid DOT 4
-
