7
9929399 R01 - 2018-2019 RANGER XP/ CREW 900/1000 Service Manual
© Copyright Polaris Industries Inc.
7.3
GENERAL INFORMATION - FINAL DRIVE
SERVICE NOTES - FINAL DRIVE
WARNING
Serious injury may result if machine tips or falls. Be
sure machine is secure before beginning any service
procedure that requires lifting the vehicle. Always wear
eye protection.
CAUTION
Switching to AWD while the rear wheels are spinning
may cause severe drive shaft and gearcase damage.
Always switch to AWD while the rear wheels have
traction or are at rest.
SPECIAL TOOLS - FINAL DRIVE
TOOL DESCRIPTION
PART NUMBER
Roll Pin Removal Tool 2872608
Axle Boot Clamp Tool PU-48951
CV Boot Clamp Pliers
8700226
Bosch Automotive Service Solutions:
1-800-345-2233 or http://polaris.service-solutions.com
SERVICE SPECIFICATIONS - FINAL DRIVE
PART DESCRIPTION
SERVICE
SPECIFICATION
Front Gearcase Coil
Resistance
21.6 - 26.4 Ω
Front Gearcase Oil
Capacity
8.0 oz (240 mL)
FINAL DRIVE
