Polaris RANGER XP 1000 2018-2019

10.16
9929399 R01 - 2018-2019 RANGER XP/ CREW 900/1000 Service Manual
© Copyright Polaris Industries Inc.
HEATER ASSEMBLY VIEW (PKG ONLY)
REF PART DESCRIPTION REF PART DESCRIPTION REF PART DESCRIPTION
q
HEATER SYSTEM
s
VENT, RECTANGULAR
2!
FLOOR, FRONT
w
GROMMET, ELECTRICAL
d
DUCT, UPPER
2@
COVER, DRIVE SHAFT
e
SEAL, HVAC
f
STRAP, PANDUIT
2#
HOSE, 1/2” HEATER
r
DISTRIBUTOR
g
VENT, SQUARE
2$
HOSE, 1/2” HEATER
t
RIVET
h
DASH, STORAGE
2%
FOAM, HOSE
y
DUCT, FOOT
j
COVER, HVAC
2^
K-BUTT SPLICE
u
VENT, ROUND
k
DASH PANEL, LOWER
2&
CLAMP, HOSE WORM GEAR
i
SCREW
l
DASH PANEL, UPPER
2*
STRAP, PANDUIT
o
SEAL, DEFROST
1(
DASH PANEL, CONTROLS
a
SEAL, DASH, CENTER
2)
CONTROL, HVAC
BODY / FRAME
