Polaris RANGER XP 1000 2018-2019

10
9929399 R01 - 2018-2019 RANGER XP/ CREW 900/1000 Service Manual
© Copyright Polaris Industries Inc.
10.15
CAB FRAME / HEADRESTS / SIDE NETS ASSEMBLY VIEW - CREW
*Vehicles with bucket seats and doors do not include Side Nets, Hip Bolster, or Head Rests.
REF DESCRIPTION REF DESCRIPTION REF DESCRIPTION
q
FRAME, CAB REAR
o
NUT, NYLOK
k
NUT
w
SCREW
a
HIP BOLSTER, PSGR
l
PLUG, FENDER
e
NUT, FLANGE
s
HIP BOLSTER, DRVR
1(
BOLT
r
FRAME, CAB FRONT
LH
d
SCREW
2)
HANDLE, GRAB
t
FRAME, CAB FRONT
RH
f
NUT
2!
BOLT
y
FRAME, CAB SIDE LH
g
FRAME, CAB MIDDLE
2@
RIVET
u
FRAME, CAB SIDE RH
h
HEADREST
2#
BOLT
i
SCREW
j
PLATE, WINDSHIELD
MOUNT
BODY / FRAME
