9929399 R01 - 2018-2019 RANGER XP/ CREW 900/1000 Service Manual
© Copyright Polaris Industries Inc.
FUEL VENT LINE ROUTING
The fuel tank is vented through a vent line. The vent line is routed from the fuel tank underneath the driver seat and
tucked into a horizontal section of the frame
w
as shown. The vent line is secured along the middle section of the line
q
.
NOTICE
Image orientation is from the rear passenger-side of the vehicle.
FUEL SYSTEM
