10.20
9929399 R01 - 2018-2019 RANGER XP/ CREW 900/1000 Service Manual
© Copyright Polaris Industries Inc.
HEATER REMOVAL / INSTALLATION (PKG
ONLY)
1. Drain the engine coolant from the radiator. Refer to
“Radiator Removal / Coolant Drain”page 3.108
procedure.
2. Remove the dash panels and glove box. Refer to
“Dash Panels / Glove Box Removal”page 10.30
procedure.
3. Disconnect the fan harness from the main harness.
4. Remove the fasteners holding the HVAC duct to the
heater system.
5. Disconnect the coolant hoses from the heater
system.
6. Remove the fasteners holding the heater system to
the body panel.
7. Reverse removal process for installation. Torque
heater system mounting fasteners to specification.
TORQUE
Heater Mounting Fasteners:
6–8 lb-ft (8–10 Nm)
BODY / FRAME
