DOOR REMOVAL / INSTALLATION (LE /
PKG ONLY)
Half Doors
1. Remove the fasteners that hold the door to the upper
and lower hinge brackets.
2. Remove the fasteners that hold the upper and lower
hinge brackets to the frame.
3. For installation, reverse removal. Install fasteners and
torque to specification.
TORQUE
Half Door Hinge to Frame Fasteners: 8 lb-ft (10 Nm)
Half Door Hinge Fasteners: 14 lb-ft (19 Nm)
Full Doors
1. Remove the fasteners that hold the door to the lower
hinge bracket.
2. Remove the fasteners that hold the door to the upper
hinge bracket. Remove the door from the vehicle.
3. Remove the fasteners that hold the upper hinge
bracket to the frame.
4. For installation, reverse removal procedure. Install
fasteners and torque to specification.
TORQUE
Full Door Hinge Fasteners:
17 lb-ft (23 Nm)
