SERVICE SPECIFICATIONS - BRAKE SYSTEM
FRONT BRAKE SYSTEM
ITEM
STANDARD SERVICE LIMIT
Front Brake Pad Thickness
0.297 ± .007" (7.54 ± .178 mm) 0.150" (3.8 mm)
Front Brake Disc Thickness
0.188" ( 4.78 mm) 0.170" (4.32 mm)
Front Brake Disc Thickness Variance
-
0.002” (0.051 mm)
Front Brake Disc Runout
-
0.010" (0.254 mm)
Front Caliper Piston Bore I.D. 1.373" (34.87 mm) 1.375" (34.93 mm)
Front Caliper Piston O.D. 1.370" (34.80 mm) 1.368" (34.75 mm)
REAR BRAKE SYSTEM
ITEM
STANDARD SERVICE LIMIT
Rear Brake Pad Thickness
0.298 ± .007" (7.56 ± .178 mm) 0.150" (3.8 mm)
Rear Brake Disc Thickness
0.188" (4.78 mm) 0.170" (4.32 mm)
Rear Brake Disc Thickness Variance
-
0.002” (0.051 mm)
Rear Brake Disc Runout
-
0.010" (0.254 mm)
Rear Caliper Piston Bore I.D. 1.505" (38.23 mm) 1.507" (38.28 mm)
Rear Caliper Piston O.D. 1.500" (38.10 mm) 1.498" (38.05 mm)
