Rear Brushguard
1. Remove the fastener holding the rear brushguard to
the frame.
2. For installation, reverse removal procedure. Torque
fasteners to specification.
TORQUE
Rear Brushguard Fasteners:
12 lb-ft (16 Nm)
NERF BAR REMOVAL / INSTALLATION
(PKG ONLY)
1. Remove the fasteners holding the front nerf bar
mounting bracket to the frame.
2. Remove the fasteners holding the rear nerf bar
mounting bracket to the frame. Remove the nerf bar
from the vehicle.
3. For installation, reverse removal procedure. Torque
fasteners to specification.
TORQUE
Nerf Bar Fasteners:12–15 lb-ft (16–20 Nm)
